+Alias Studio Modeling for Tooling Level 4

Course Duration: 40 hours

Tuition: $2200.00

Overview: General principles of product design as related specifically to manufacturing. This is not an A-Class surfacing workshop.

Prerequisite: Industrial Design degree helpful but not necessary. This workshop has been designed for experienced Alias Studio users.

Topics:

• Modeling techniques for the core tools with respect to tooling data
• Master blend curves, align functions and surface fillets.
• Parameterization
• The forty hour workshop can be tailored to work with individual or corporate projects.
• Draft techniques for production tooling.

Discussion:

• Discuss the difference between Bezier and NURBS
• Learn about CV distribution and span distribution
• Discuss with examples global evaluation, and diagnostic shading.
• discuss with examples the import process for taking tooling data into engineering tools such as Solidworks or Pro/ENGINEER

Projects:

• Blow molded bottle design
• Cellular product design project
• Diecast Stapler
